TX150 S6 Options Guide 37
Accessible drives Installing a 3.5-inch floppy disk drive
6.2 Installing a 3.5-inch floppy disk drive
The 3.5-inch bay for the optional floppy disk drive is positioned between the hard
disks cage and the 5.25-inch bays for accessible drives.
Ê Open the server and remove the front cover or the rack front cover as
described in the chapter “Preparation” on page 21 et seq..
Ê From the inside press out the 3.5-inch dummy cover on the front cover.
V CAUTION!
Keep the dummy cover in a safe place. If you remove the accessible drive
again and do not replace it with a new one, the dummy cover must be
reinstalled to comply with EMC regulations and to satisfy cooling require-
ments and fire protection measures.
Figure 21: Removing the floppy disk drive holder
Ê Remove the two screws (1) that attach the drive holder to the housing front.
Ê Pull on the drive holder and completely remove it from the server (2).
1
2
