Fujitsu PRIMERGY TX150 S6

TX150 S6 Options Guide 27
Preparation Rack model
Figure 9: Removing the top cover
Ê Unlock the top cover by removing the two screws on the server rear (1).
Ê Push the top cover to the rear approxiate 2 cm (2).
Ê Lift off the top cover upwards (3).
2
3
2
1
