Working with the Tablet PC
Your Cradle (optional)
Your cradle is a device which can help y ou to quickly connect your Tab let PC to your
peripheral devices such as a display screen, k eyboard, mouse etc.
You need only do ck the Tablet PC in order to work with your peripheral devices.
Cradle components
PortsPortsCradle
1
2
3
5
4
4
4
1 = Connector on the cradle for the docking
port of the Tablet PC
2 = Docking guide for the Tablet PC
3 = DC input co nnector ( DC IN)
4 = USB ports (USB 2.0)
5 = LAN port
SettinguptheCradle
Select a suitable location for the Cradle before setting it up. Follow
the instructions below when doing so:
• PlacetheCradleonaflat, stable, nonslippery surface.
• Never place the Cradle and the mains adapter o n a heat-sensitive surface.
• Do not expose the Cradle to extreme environmen tal conditions.
Protect the Cra dle from dust, humidity a nd heat.
Fujitsu 51
