Working with the Table t PC
Connecting the Tablet PC to the Cradle
It is possible to connect the Tablet PC to the cradle du ring operation. To prevent
problems, we recommend that you switch the Tablet PC off first.
Disconnect t he mains adapter from the Tablet PC bef ore co nnecting
the Tablet PC to the cradle.
If the Tablet PC is connected to the Crad le, you must connect the
mains adapter to the Cradle.
Cradle
► Switch off the Tablet PC .
► Remove the power plug of th e mains adapter from the mains socket.
► Pull the mains adapter cable out o f the DC jack (DC IN) of the Tablet PC.
1
2
4
3
► Position the Tablet PC so th at it is in line with the storage space of the Cradle.
► Push the Tablet PC on to the Cradle in the direction of the arrow (1) until
you notice it engage with the plug.
► Plug the DC output connector on the mains adapter into the DC input
connector (DC IN) on the Cradle (2).
► Connect the power cable to the mains adapte r (3).
52 Fujitsu
