103
Disconnect the 3 electrical connectors:
Extruder motor: This wire plugs into the white socket on the rear of the extruder. DO NOT tug on this
connector by the wires as you may break them. Grasp the top and bottom of the connector body (there
are some small flanges you can grab with your fingernail) and remove it from the motor. It does not
have a latch; it’s just a friction fit.
Extruder fan: This is a 2-pin black connector that’s positioned just behind the extruder. It has a latch so
make sure you disengage the latch before trying to separate the connector.
