18
5 Control Panel Information
The control panel is a full color resistive-type touchscreen that gives you full control over your F410. It
also contains an SD card reader and a hardware “stop/reset” button.
1. Touchscreen interface (see below for more detail)
2. Hardware “stop/reset” button. Pressing this button will immediately cause your printer to stop
what it’s doing and reboot. It’s useful if something goes wrong and you want the printer to stop
immediately. When you press this button the motors will be switched off and power will be cut
off from the bed heater and print head.
3. SD card reader (on bottom face)
4. “DO NOT OPERATE EQUIPMENT UNATTENDED” warning. Please do not operate your F410
without supervision and monitoring.
5.1 Touchscreen Interface
Your F410’s touchscreen interface has been designed to be intuitive and easy to use, while still
providing access to advanced functionality when it’s needed. The interface is divided into two main
areas:
Print: functions and controls you will need to begin a print, and monitor a print in progress.
Maintain Printer: functions and controls you will need to perform diagnostics, maintenance, or
other functions.
