105
<Model Menu (Common Functions)>
the setup screen shown below.
AFR function is used to adjust the throw and
operation curve of the stick, lever, and switch
This is normally used after End Point (ATV) has
acts on ALL flight condition settings). When
mixing is applied from one channel to another
channel, both channels can be adjusted at the same
time by adjusting the operation rate through the
AFR function.
points curve can be used for the line and
The number of points can also be increased
and decreased and curves from complex
curves to simple curves can be used.
speed of each function when the function
is operated (including at flight condition
switching) can be adjusted. The function
operates smoothly at a constant speed
corresponding to the set speed.
(Currently selected condition name)
(Currently selected rate name: AFR, D/R1~6)
Function selection
(Total number of AFR
and D/R curves set in
the currently selected
condition)
(For a description of the setting method,
see the description at the back of this
manual.)
When setting the D/R function, the screen display mode
can be changed. Each time the button is touched, the mode
is switched.
curve is displayed.
condition are displayed.
displayed.
(For more information, see the description at the back of this manual.)
(For a description of the setting method, see the description at the
back of this manual.)
