<Model Basic Setting Procedure>
1. Model addition and call
Default settings assign one model to the T18MZ
transmitter. To add new models or select previously
setup models, use the Model Select function in the
Linkage Menu.
This is convenient when calling a model after
registering the model names in advance. (Data can also
be saved to the accessory SD card and USB memory)
The currently called model is displayed at the top
Please be aware that the transmitter will stop
transmitting when you change the model.
When a new model was added, the Model type select
screen/System mode/Receiver link automatically
appear. Please be aware that the transmitter will
stop transmitting when you change the model.
2. Model type and swash type selection
When a separate model type is already selected,
select helicopter with the Model Type function of the
Linkage Menu, and then select the swash type matched
to the fuselage.
Helicopter basic setting procedure
3. Flight condition addition
The transmitter can install up to eight flight
conditions per model. You can assign all switches
including sticks, switches, trim levers and trim switches
as flight-condition selection switches. You can also
add delayed mixing to these functions in order to
avoid sudden changes. Moreover, you can set priority
condition. In addition, you can copy conditions and/or
change names of conditions. This command may also
be used to define what switches and/or controls are
The Condition Select function automatically
when a new model type is defined. This condition is
always on, and remains on until other conditions are
activated by switches.
The Condition Delay can be programmed for each
channel. The Condition Delay is used to change the
servo throw smoothly when switching conditions.
The priority is throttle hold/idle up 2/idle up 1/
normal. Throttle hold has the highest priority.
Add other conditions, as required.
