158
<Data>
0RYH
'HOHWH
Line and spline curve adjustment
Line curves or spline curves of up to 17 points
can be used. (Initial value: 7/9 points) The set
points can be freely increased, decreased, and
offset. Curves which are symmetrical to the left and
right of center can also be set.
*[Separate] mode: Normal setting
*[Combined] mode: Creates a left and right
symmetrical curve.
the selected point.)
2. Touch the Rate button.
rate.
[Point addition method]
stick, etc. to the point you want to add and
appears on the graph.)
outlined point appears on the graph.)
3. Touch the Insert button.
[Point deletion]
is the selected point.)
selected point becomes an outlined point.)
*The point is deleted.
The curve can also be offset horizontally in the
vertical direction.
*Initial value: +0.0%
(Line curve)
(Spline curve)
To Next Page
