62
<Model Basic Setting Procedure>
*For this curve, use the initial setting [Linear] curve type and
adjust the left and right rates in the [Separate] mode.
*For this curve, [Linear] curve type can be used and the entire
curve can be lowered with the [Offset] button.
*For this curve, [Linear] curve type can be used and the entire
curve can be lowered with the [Offset] button.
pitch interaction
The swash mix function is used to correct the
swash plate in the aileron (roll) direction and
elevator (cyclic pitch) corresponding to each
operation of each condition.
RPM loss caused by swash operation of aileron
or elevator can be corrected with the Throttle
Mix function in the Model Menu. The effects of
clockwise and counterclockwise torque is applied
when pirouetting can also be corrected.
The gyro sensitivity and mode switching
function is dedicated gyro mixing of the Model
Menu, and can be set for each condition.
11. Throttle cut setting
Throttle cut provides an easy way to stop the
at idle. The action is not functional at high throttle
to avoid accidental dead sticks. The switch’s
location and direction must be chosen, as it defaults
*With throttle stick at idle, adjust the cut position
until the engine consistently shuts off, but throttle
linkage is not binding. When finished, touch the
“Throttle Cut” button to exit.
To Next Page
