Garmin G1000 System Maintenance Manual

Page 7-38 G1000 / GFC 700 System Maintenance Manual - 300/B300 Series King Air
Revision 4 190-00716-01
7.17 FliteCharts Functional Check
Reference Section 3.35, FliteCharts Configuration, for configuring FliteCharts.
NOTE
This test is not required if ChartView is enabled.
1. With the G1000 in Normal Mode, use the GCU FMS knob to select ‘AUX – System Status’ page,
then select MFD1 DB softkey.
2. Use the small FMS knob to scroll to CHART.
3. Verify “FliteCharts” is displayed in blue text adjacent to “CHART”.
4. Verify the FliteCharts database cycle number is displayed in blue text and the FliteCharts database is
current.
5. Deactivate the cursor and use the GCU large FMS knob to select the Navigation Map Page then
press the SHW CHRT softkey.
6. Verify the airport chart is displayed and the following softkeys are displayed (some softkeys may be
grayed out):
• CHRT OPT
• CHRT
• INFO-1
• DP
• STAR
• APR
• WX
• NOTAM
• GO BACK
7. Press the CHRT OPT softkey and verify the following softkeys are displayed (some softkeys may be
grayed out):
• ALL
• HEADER
• PLAN
• PROFILE
• MINIMUMS
• FIT WDTH
• FULL SCN
• BACK
If no other service is to be performed, continue to the return-to-service checks in Section 8.

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
