G1000 / GFC 700 System Maintenance Manual - 300/B300 Series King Air Page 3-29
190-00716-01 Revision 4
3.15 GDL 59 Wi-Fi Data Link Option Configuration
Follow this procedure to enable the optional GDL 59 Wi-Fi data link function.
NOTE
If the GDL 59 option is reloaded for any reason, the GSR 56 option must also
be reloaded per Section 3.16. Coordinate the GDL 59 configuration with
Section 7.29 “GDL 59 Wi-Fi Data Link Functional Check”.
1. With the loader card in the top slot of PFD1 and PFD1 in configuration mode, select the
SYSTEM UPLOAD” page using the small FMS knob on PFD1.
2. Activate cursor and rotate the small FMS knob to display the drop down menu. Rotate the small
FMS knob to highlight “King Air – Garmin Options” and press ENT key on PFD1.
3. Rotate the small FMS knob to highlight “King Air - GDL 59”. Press ENT key on PFD1.
4. Verify “King Air - GDL 59” is displayed in the “Item” window. Press “LOAD” softkey.
5. Monitor load progress. Verify software load completes without errors as indicated by the
following:
Green “PASS” in Configuration and Software columns for each item loaded
“Upload Complete………….COMPLETE” in the summary box.
6. Press ENT key on PFD1 to acknowledge upload complete.
7. Deactivate cursor.
