G1000 / GFC 700 System Maintenance Manual - 300/B300 Series King Air Page 7-39
190-00716-01 Revision 4
7.18 ChartView Functional Check
ChartView must be enabled using a ChartView Enable Card, as specified in the General Arrangement
Drawing listed in Table 1-2, and a current ChartView database. Reference section 3.36, “ChartView
Configuration” for enabling procedures.
NOTE
The required ChartView databases are subscription-based and are to be procured by the
aircraft owner directly from Jeppesen.
1. With the G1000 in Normal Mode, use the GCU FMS knob to select ‘AUX – System Status’ page, then
select MFD1 DB softkey.
2. Use the small FMS knob to scroll to CHART.
3. Verify “ChartView” is displayed in blue text adjacent to CHART.
4. Verify the ChartView database cycle number is displayed in blue text and the ChartView database is
current.
5. Deactivate the cursor and use the large GCU FMS knob to select the Navigation Map Page then press
the SHW CHRT softkey.
6. Verify the airport chart is displayed and the following softkeys are displayed(some softkeys may be
grayed out):
• CHRT OPT • APR
• CHRT • WX
• INFO-1 • NOTAM
• DP • GO BACK
• STAR
7. Press CHRT OPT softkey and verify the following softkeys are displayed (some softkeys may be
grayed out):
• ALL
• HEADER
• PLAN
• PROFILE
• MINIMUMS
• FIT WDTH
• FULL SCN
• BACK
If no other service is to be performed, continue to the return-to-service checks in Section 8.
