G1000 / GFC 700 System Maintenance Manual - 300/B300 Series King Air Page 3-49
190-00716-01 Revision 4
3.32 ESP Support Option Configuration
This section applies only to installations with the ESP option. The procedures outlined in this section
must be followed to load the necessary configuration files required to enable ESP messages and functions.
An Enhanced AFCS unlock card is also required for this option (see Section 3.41). Coordinate this
configuration with Section 7.26 “ESP Functional Check”.
1. With the loader card in the top slot of PFD1 and PFD1 in configuration mode, select the
“SYSTEM UPLOAD” page using the small FMS knob on PFD1.
2. Activate cursor and rotate the small FMS knob to display the drop down menu. Rotate the small
FMS knob to highlight “King Air – Airframe Options” and press ENT key on PFD1.
3. Rotate the small FMS knob to highlight “King Air - ESP Support (no AOA)”. Press ENT key
on PFD1.
4. Verify “King Air - ESP Support (no AOA)” is displayed in the “Item” window. Press “LOAD”
softkey.
5. Monitor load progress. Verify software load completes without errors as indicated by the
following:
• Green “PASS” in the Configuration column for each item loaded.
• “Upload Complete………….COMPLETE” in the summary box.
6. Press ENT key on PFD1 to acknowledge upload complete.
7. Deactivate cursor.
