Page 3-48 G1000 / GFC 700 System Maintenance Manual - 300/B300 Series King Air
Revision 4 190-00716-01
3. Verify that the DATA window shows the following:
Hdg:
None:
J3-1 Jumper
J3-2 Jumper
Hdg Valid
Flag
No Fla
Flag Sense +invld
J3-4 Open
Hdg Value
<aircraft
heading>
Inhibit
Line
Off
Antenna
Mount
Bottom
J3-3 Open
4. Deactivate the cursor.
NOTE
The DATA window is only updated once every five seconds.
