JF-240UV User Manual
72
Panel size The panel splits the job into tiles and is output by the software. If the panel reduces
in size so that it does not cover the entire job, only the parts covered by the panel
are output.
Shows the width and height of the panel. To adjust, enter a number or use
the spinner controls.
The size of the margin. The margin is the part of the panel that extends
outside of the boundaries of the job.
Selected tile Selects which tile's width and height display in the fields below.
Selects a tile to edit. The selected tile highlights in the preview pane.
Shows the width and height of the selected tile. To adjust, enter a number
or use the arrows.
Print Check to output the selected tile with the rest of the job.
Clear to prevent output by marking the tile with a mesh overlay in the preview pane
All tiles These settings apply to all tiles and help you quickly set up automatic tiles of equal size.
Selecting this option divides the job vertically into the number of columns
specified. Each column is of equal width.
Selecting this option divides the job into the number of rows specified. Each
row is of equal height.
Enter the values for the width and height of the tiles here. All tiles change to
the specified size.
Set the amount of overlap between tiles. Enter a negative number to create an
offset between tiles.
Reset Restores the default settings.
Automatic tile flip Check to rotate every other printed tile 180° so that adjacent vertical edges
always print with the same side of the print head. This helps them match up
cleanly.
