GDC SX-3000 - Pci

2. SMS
- 34 -
April 20, 2015
SX-3000 Standalone Integrated Media Block™ with
Portable Storage/ Enterprise Storage User Manual
2.3.5.3.4. PCI
Figure 19 SNMP Configuration [PCI].
1
On the SNMP Configuration menu, select PCI. A new window opens as seen in Figure 19
above.
2
Activate the Trap by checking the small box opposite the corresponding
PCI Device .
NOTE: When the Trap is On, a trap is sent when the corresponding PCI device is missing.
2
1
