2.3.5.3.5. Sensors
Figure 20 SNMP Configuration [Sensors].
1
On the
SNMP Configuration menu, select Sensors. A new window opens as seen in Figure 20
above.
2
Set the threshold temperature required for the system sensors by typing in the field or using
an on-screen keyboard
. Activate the Trap by checking the small box opposite System
Temperature Threshold
.
NOTE: When the Trap is On, a trap is sent if the system temperature exceeds the
maximum threshold temperature.
