CG10 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
PROFIBUS-DP COMMUNICATIONS CGCOMMUNICATIONS GUIDE
2 8 EmergencySwitchTrip
3 8 DifferentialSwitchTrip
4 8 SpeedSwitchTrip
5 8 ResetSwitchTrip
68Reserved
7 8 OverloadTrip
89ShortCircuitTrip
99ShortCircuitBackupTrip
10 9 MechanicalJamTrip
11 9 UndercurrentTrip
12 9 CurrentUnbalanceTrip
13 9 GroundFaultTrip
14 9 GroundFaultBackupTrip
15 9 Reserved
16 10 AccelerationTimerTrip
17 10 Rtd1Trip
18 10 Rtd2Trip
19 10 Rtd3Trip
20 10 Rtd4Trip
21 10 Rtd5Trip
22 10 Rtd6Trip
23 10 Rtd7Trip
24 11 Rtd8Trip
25 11 Rtd9Trip
26 11 Rtd10Trip
27 11 Rtd11Trip
28 11 Rtd12Trip
29 11 UnderVoltageTrip
30 11 OverVoltageTrip
31 11 VoltagePhaseReversalTrip
32 12 UnderfrequencyTrip
33 12 OverfrequencyTrip
34 12 LeadPowerFactorTrip
35 12 LagPowerFactorTrip
36 12 PositivekvarTrip
37 12 NegativekvarTrip
Table CG–3: Profibus Diagnostics (Sheet 2 of 7)
BIT BYTE FUNCTION
