CGCOMMUNICATIONS GUIDE PROFIBUS-DP COMMUNICATIONS
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG11
38 12 UnderpowerTrip
39 12 ReversePowerTrip
40 13 IncompleteSequenceTrip
41 13 SpareSwitchAlarm
42 13 EmergencySwitchAlarm
43 13 DifferentialSwitchAlarm
44 13 SpeedSwitchAlarm
45 13 ResetSwitchAlarm
46 13 Reserved
47 13 ThermalCapacityAlarm
48 14 OverloadAlarm
49 14 MechanicalJamAlarm
50 14 UndercurrentAlarm
51 14 CurrentUnbalanceAlarm
52 14 GroundFaultAlarm
53 14 UndervoltageAlarm
54 14 OvervoltageAlarm
55 14 OverfrequencyAlarm
56 15 UnderfrequencyAlarm
57 15 LeadPowerFactorAlarm
58 15 LagPowerFactorAlarm
59 15 PositivekvarAlarm
60 15 NegativekvarAlarm
61 15 UnderpowerAlarm
62 15 ReversePowerAlarm
63 15 Rtd1Alarm
64 16 Rtd2Alarm
65 16 Rtd3Alarm
66 16 Rtd4Alarm
67 16 Rtd5Alarm
68 16 Rtd6Alarm
69 16 Rtd7Alarm
70 16 Rtd8Alarm
71 16 Rtd9Alarm
72 17 Rtd10Alarm
73 17 Rtd11Alarm
Table CG–3: Profibus Diagnostics (Sheet 3 of 7)
BIT BYTE FUNCTION
