Revision C 250cx Series Maternal/Fetal Monitor 5-31
2036947-001
Troubleshooting: FAQs
How do I change the Recorder Paper
Speed?
1. Enter the General Setup Screen.
2. Rotate the Trim Knob to highlight the Paper Speed: setting in the Recorder Setup
section of the General Setup screen (center section of the display).
3. The current setting is one of the following: 1, 2, or 3 cm/min.
4. Once the Paper Speed: setting is highlighted, press the Trim Knob again. The
current setting displays in blinking inverse video.
5. Now rotate the Trim Knob to change the current setting. Select a value.
6. Once you set the desired value, press the Trim Knob again to save the value. The
current value setting stops blinking.
7. To exit the Service mode, follow the instructions at the top of Page 16.
How do I enable the maternal-only recorder
mode?
1. From the On state, (The yellow LED above the recorder is illuminated.), press the
Record button once quickly. The recorder advances, printing the date and time on
the chart paper perpendicular (rather than parallel) to the direction of paper travel.
Then the recorder halts and the yellow LED flashes intermittently to indicate
MATERNAL ONLY mode is enabled.
2. From the Off state, (The yellow LED above the recorder is off.), press the Record
button twice quickly. The recorder advances, printing the date and time on the chart
paper perpendicular (rather than parallel) to the direction of paper travel. Then the
recorder halts and the yellow LED flashes intermittently to indicate MATERNAL
ONLY mode is enabled.
How do I turn off the recorder completely? From the On or MATERNAL ONLY state, (The yellow LED above the recorder is
illuminated or flashing intermittently.), press the Record button and hold for 2 seconds,
until the monitor emits a two tone audio beep which indicates that the recorder is off.
The yellow LED is now extinguished.
How do I change the LOW PAPER/NO
PAPER alarm conditions?
1. Enter the Install Options Screen 1. Rotate the Trim Knob to highlight the Paper
Chime: setting.
2. The current setting is one of the following: Off (no audio for any 'no paper' or 'low
paper' condition), Out Only (audio tone on 'paper out' only), or Low/Out (audio tone
for any LOW PAPER/NO PAPER condition).
3. Once the Paper Chime: setting is highlighted, press the Trim Knob again. The
current setting displays in blinking inverse video.
4. Now rotate the Trim Knob to change the current setting. Select a value.
5. Once you set the desired value, press the Trim Knob again to save the value. The
current value setting stops blinking.
6. To exit the Service mode, follow the instructions at the top of Page 16.
How do I change the Heart Rate Recorder
Scale?
1. Enter the Install Options Screen 1. (“How do I access the service setup /
install options screens?” on page 5-27).
2. In Install Options Screen 1, rotate the Trim Knob to highlight the Scaling: setting.
3. The current setting is either 30-240 or 50-210 bpm.
4. Once the Scaling: setting is highlighted, press the Trim Knob again. The current
setting displays in blinking inverse video.
5. Now rotate the Trim Knob to change the current setting. Select a value.
6. Once you set the desired value, press the Trim Knob again to save the value. The
current value setting stops blinking.
7. To exit the Service mode, follow the instructions at the top of Page 16.
Question Answer
