GE LOGIQ 5 Service Manual

GE MEDICAL SYSTEMS
DIRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
8-102 Section 8-8 - PC Block
8-8-1-4 General Procedures of BEP2 Assy Disassembly (cont’d)
13.)When replace the BEP assy the option dongle should be moved from old BEP to new one. The FRU
BEP doesn’t have the option dongle.
General Procedures of BEP3 Assy Disassembly.
Figure 8-99 Option Dongle replacement
Figure 8-100 BEP3 Option Dongle replacement
Option Dongle
VGA to VIC Cable
Option Dongle
VGA to VIC Cable
