GE LOGIQ 5 Service Manual

GE MEDICAL SYSTEMS
D
IRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-123
8-8-1-8 Check the Device Driver Configuration.(BEP2)
After System boot up. confirm the installed device information.
Double click Go Device Manager Icon
1.) Check VGA Driver and PCI Video Driver are enrolled on Display adapter section.
2.) Check The PCI Bridge Between FEC Assy and PC2IP Assy under multi function adapters
3.) Check the Sound Driver is On board Sound (Sound Max).
4.) Check the VIC Assy Driver is GE Medical SuperSonic Diagnostic Device Driver and GEMSK
Multimedia Device
5.) Check The USB Device Driver.
Figure 8-126 Device Manager
Figure 8-127 Display Adapter
Figure 8-128 Multi Function Adapter
Figure 8-129 Sound Driver
Device Manger
VIC assy
On board sound
