GE MEDICAL SYSTEMS
DIRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
8-144 Section 8-8 - PC Block
8-8-2-5 Mounting procedure (cont’d)
Case 4. BEP4
3.) Perform the following functional tests. If all are successful, include the debrief script provided below.
8-8-2-6 Mounting Procedure
Install the new parts in the reverse order of removal.
Figure 8-168 BEP4
Table 8-48 Functional Tests
Service Manual
Section Functional Test / Diagnostic Test Debrief Script
Section 4-3-1
Power On/Boot Up
“Service Manual, Direction
2300000, Rev 1+, Section 8-8-2. Equipment
passed all required tests and is ready for use. “
Section 4-3-2
Power Off / Shutdown
Section 4-9-12
VIC Assy function check procedure
Section 4-3-4
System B/M-Mode Checks
Section 4-3-5
System CFM and PWD Checks
Section 10-5-2
Functional Checks (See Also Chapter 4)
Section 10-6
Using a Phantom
