IRECTION 2300000, REVISION 1 LOGIQ™ 5 SERVICE MANUAL
Chapter 9 - Renewal Parts 9 - 7
Section 9-6 KEYBOARD BLOCK (cont’d)
Table 9-3 COMMON KEYBOARD SPARE PARTS
Item Part Name
Part
Number Description Qty FRU
200
KB ASSY 2299986-4 INCLUDE LCD COVER 1 1
201
KB FRONT GRIP 2299984-2 PLASTIC GRIP 1 2
202
PROBE HOLDER 2300010 INCLUDE CUP HOLDER 1 2
203
ECG CABLE HOOK 2283028 PLASTIC HOOK 1 2
204
OP PANEL ENCODER ASSY 2317341 ALL ENCODERS WITH CABLES 1 1
205
OP PANEL TGC ASSY 2317342 TGC WITH KNOB 1 1
206
TGC KNOB SET 2356244 TGC KNOBS 1 1
207
OP PANEL A/N KEY BOARD ASSY 2317343 BOARD OF A/N KEY SWITCH 1 1
208
OP PANEL TRACKBALL ASSY 2317344 Common with LOGIQ 3 1 1
209
HUB BOARD ASSY 2331557 CIRCUIT BOARD 1 1
210
OP PANEL LCD ASSY 2317346 CIRCUIT BOARD 1 1
211
LCD ENCODER ASSY 2331741 CIRCUIT BOARD 1 1
212
P KEY LABEL 2364143 USER DEFINED KEY LABEL 1 1
213
GEL HOLDER 2384742 1 1
214
ITV BLOCK 2384743 1 2
215
FREEZE KEY 2384744 1 2
216
KEYBOARD MAIN BOARD 2384745 KEYB’D MAIN PCB BOARD 1 2
217
PROBE HOLDER BRACKET 2384746 1 1
221
HUB ASSY 2385577 FOR LOGIQ 5 ONLY 1 1
