9 - 18 Section 9-3 - Renewal Parts Lists
Section 9-12
Options, Peripherals and Cables
Table 9-9 CABLES
Table 9-10 PROBES
Table 9-11 OPTION SVC PARTS
Item Part Name Part Number Description Qty FRU
800 OP CABLE ASSY 2331742 CABLE SET 1 2
801 PCI CABLE 2363523 CABLE SET 5 3
802 PC CABLE ASSY 2331743 CABLE SET 6 2
803
POWER CABLE ASSY
2331744 110V FOR JAPAN AND USA 6 2
2356242 220V FOR EUROPE 6 2
Item Part Name Part Number Description Qty FRU
804 3C PROBE (EXP) 2286354 PROBE 1 1
805 3.5C PROBE (EXP) 2296158 PROBE 1 1
806 5C PROBE (EXP) 2294516 PROBE 1 1
807 E8C PROBE (EXP) 2294641 PROBE 1 1
808 10L PROBE (EXP) 2294523 PROBE 1 1
809 12L PROBE (EXP) 2295377 PROBE 1 1
810 3S PROBE(EXP) T3308LZ 2250695 PROBE 1 1
Item Part Name Part Number Description Qty FRU
811 FIXTURE FOR B/W PRINTER 2355253 OPTION SVC PART 1 1
812
Fixture for VCR/Color Printer,Side
Pocket
2355254 OPTION SVC PART 1 1
813 Fixture for VCR/Color Printer TOP 2355255 OPTION SVC PART 1 1
814 CABEL SET FOR B/W PRINTER 2355256 OPTION SVC PART 1 1
815 CABEL SET FOR COLOR PRINTER 2355257 OPTION SVC PART 1 1
816 CABEL SET VCR 2355258 OPTION SVC PART 1 1
817 MOD 2355259 OPTION SVC PART 1 1
818 ECG KIT 2355260 OPTION SVC PART 1 1
819 INSITE KIT 2355261 OPTION SVC PART 1 1
820 SWIVEL LOCK 2355262 OPTION SVC PART 1 1
821 CWD KIT 2380140
FOR SYSTEM VER HIGER
THAN R2.0.1
11
822 CWD KIT WITH ATD ASSY 2380142
FOR SYSTEM PRIOR TO
VER 2.0.1
11
