Chapter 10 Care & Maintenance 10-15
7.) Follow the test conditions described for respective test points shown in Table 10-15.
8.) Keep a record of the results with other hard copies of PM data kept on site.
10-8-1-3 Data Sheet for Chassis Source Leakage Current
The test passes when all readings measure less than the value shown in Table 10-12. Record all data
on the PM Inspection Certificate.
Table 10-15 Chassis Leakage Current Test Condition
TEST CONDITION
1
Mounting screw for probe receptacle
2
caster support
3
Mounting screw for CRT housing
4
Mounting screw for peripheral plugged into unit
5
Mounting screw for other peripheral powered by unit
Table 10-16 Typical Data Sheet for Chassis Source Leakage Current
Unit Power
Tester Polarity
Switch
Tester Neutral
or Ground
Switch
Test 1
Probe
Connector
Test 2
caster
Test 3
CRT
Optional
Test 4
Optional
Test 5
Enter Name of tested peripheral here:
ON NORM OPEN
ON NORM CLOSED
ON REV OPEN
ON REV CLOSED
OFF NORM OPEN
OFF NORM CLOSED
OFF REV OPEN
OFF REV CLOSED
To Next Page
