GE MEDICAL SYSTEMS
DIRECTION 2300000, REVISION 1 LOGIQ™ 5 SERVICE MANUAL
3 - 4 Section 3-2 - Installation Reminders
Section 3-3
Receiving and Unpacking the Equipment
When a new system arrives, check that any components are not damaged and are not in short supply.
If shipping damage or shortage occurs, contact the address shown in Chapter 1.
1.) Cut the three PLASTIC BANDs.
Figure 3-7 Cutting the Plastic Bands.
CAUTION
Do not lift the unit by the Keyboard. Equipment damage may result.
CAUTION
The crate with the LOGIQ™ 5 weighs approximately 180 kg. (397 lb) Be prepared for a sudden
shift of weight as the unit is removed from its base (pallet)
Plastic Bands
To Next Page
