GE PACSystems RX3i Command Line Interface Manual

show profinet
2-60 PACSystems* RX3iPROFINET Controller Command Line Interface Manual – July 2011 GFK-2572
2
Displaying Detailed Information about a Device’s Counters
The following example shows counter details for device number 1.
Screen Display
device-name> show profinet counters 1
01-JAN-2000 00:06:38.0000
PNCDeviceName: device-name
ProviderState: Run
Dev# Vendor Device AR# ARStat DeviceName
---- ------ ------ --- ------ ------------------------------------
001 0015h 0001h 001 LocCtrl remote-io-device1
<<< PROFINET Counters >>>
<<< Connect Counters >>>
ConnReq =00000002H ConnRsp+=00000002H ConnRsp-=00000000H ConnDif =00000001H
ApRdyDif=00000000H DiscReq =00000000H DiscRsp+=00000000H DiscRsp-=00000000H
DiscInd =00000001H AbortReq=00000000H AsyncRdy=00000000H AsyncCon=00000000H
CloseInd=00000000H RqPriReq=00000000H RqPrRsp+=00000000H RqPrRsp-=00000000H
<<< Alarm Counters >>>
AlmInd =00000000H DiagInd =00000000H ProcAlm =00000000H PullInd =00000000H
PlugInd =00000000H ManufInd=00000000H OtherInd=00000000H AlmAck+ =00000000H
AlmAck- =00000000H AlmCnf+ =00000000H AlmCnf- =00000000H
<<< IOCR Counters >>>
0:(Input CR)
LatchReq=00000000h LatchCnt=00000000h
1:(Output CR)
LatchReq=00000000h LatchCnt=00000000h
<<< SubModule Counters Per Slot/Subslot >>>
0.1
InptScns=00000000h DataLtch=00000000h BadInScn=00037c39h
OutScans=00000000h OutCltRd=00000000h BdOutScn=00000000h
1.1
InptScns=00000000h DataLtch=00000000h BadInScn=00000000h
OutScans=0000000Ah OutCltRd=0000000Ah BdOutScn=00000000h
device-name>
