show profinet
GFK-2572 Chapter 2 Monitor Level Commands 2-59
2
Screen Display
<<< IOCR 0x0001-(Output CR)-Update Period: 1 ms >>>
IOCRProperties: 0x00000001
MediaRedundancy: No media redundant frame transfer
RTClass: RT Class 1
IOCRTagHeader: 0xC000
IOCR User Priority: 6 (IO CR Priority)
Vlan ID: 0x000 (No VLAN)
Current Data Status: 0x01
Station Problem Indicator: Problem detected
Provider State: Stop
Data Valid: Invalid
State: Backup
Len FrmId SendClk(us) Ratio Phase FrmOffset WatchDg DataHold APIs
----- ----- ----------- ----- ----- --------- ------- -------- ----
0040h ffffh 1000.00 001 0001h 00000000h 0003h 0003h 001
<<< API 0 >>>
ObjType Slot# Subslot# FrmOffset ModId SubModId Leng Value
------- ----- -------- --------- --------- --------- ---- -------
OutIOCS 000h 0001h 0005h 00000001h 00000001h 0001 60h
OutIOCS 000h 0002h 0006h 00000001h FFFF010Ah 0001 60h
OutIOCS 000h 8000h 0007h 00000001h 00100000h 0001 60h
OutIOCS 000h 8001h 0008h 00000001h 00010000h 0001 60h
OutIOCS 000h 8002h 0009h 00000001h 00020000h 0001 60h
OutIOPS 000h 0001h 0004h 00000001h 00000001h 0001 60h
OutData 000h 0001h 0000h 00000001h 00000001h 0004 00h
device-name>
Displaying Detailed Information about a Device’s Alarm Status
The following example shows alarm status details for device number 1.
Screen Display
device-name> show profinet alarm 1
01-JAN-2000 00:06:38.0000
PNCDeviceName: device-name
ProviderState: Run
Dev# Vendor Device AR# ARStat DeviceName
---- ------ ------ --- ------ ------- -------------------------------
001 00B0h 0003h 001 LocCtrl remote-io-device1
<<< Alarm CR Status >>>
RTA Timeout: 100 ms
RTA Retry: 03
device-name>
