show profinet
2-58 PACSystems* RX3iPROFINET Controller Command Line Interface Manual – July 2011 GFK-2572
2
Displaying Detailed Information about a Device’s IOCRs
Note: The show profinet iocrs <device number> command displays values even when the
connection to the device is not active. When the device is disconnected, the Current
Data Status field and the Value column display the last values received. When using this
command, be aware of the device’s connection status.
The following example displays IOCR details for device number 7.
Screen Display
device-name> show profinet iocrs 7
01-JAN-2000 00:06:38.0000
PNCDeviceName: device-name
ProviderState: Run
Dev# Vendor Device AR# ARStat DeviceName
---- ------ ------ --- ------ ---------------------------------
007 0015h 0001h 003 NoCtrl remote-io-device7
<<< IOCR Status >>>
<<< IOCR 0x0000-(Input CR)-Update Period: 1 ms >>>
IOCRProperties: 0x00000001
MediaRedundancy: No media redundant frame transfer
RTClass: RT Class 1 (Data-RTC-RDU)
IOCRTagHeader: 0xC000
IOCR User Priority: 6 (IO CR Priority)
Vlan ID: 0x000 (No VLAN)
Current Data Status: 0x02
Station Problem Indicator: Problem detected
Provider State: Stop
Data Valid: Invalid
State: Primary
Len FrmId SendClk(us) Ratio Phase FrmOffset WatchDg DataHold APIs
----- ----- ----------- ----- ----- --------- ------- -------- ----
0040h c080h 1000.00 001 0001h 00000000h 0003h 0003h 001
<<< API 0 >>>
ObjType Slot# Subslot# FrmOffset ModId SubModId Leng Value
------- ----- -------- --------- --------- --------- ---- -------
InIOCS 000h 0001h 0005h 00000001h 00000001h 0001 80h
InIOPS 000h 0001h 0004h 00000001h 00000001h 0001 80h
InData 000h 0001h 0000h 00000001h 00000001h 0004 05h
InIOPS 000h 0002h 0006h 00000001h FFFF010Ah 0001 80h
InData 000h 0002h 0006h 00000001h FFFF010Ah 0000 00h
InIOPS 000h 8000h 0007h 00000001h 00100000h 0001 80h
InData 000h 8000h 0007h 00000001h 00100000h 0000 00h
InIOPS 000h 8001h 0008h 00000001h 00010000h 0001 80h
InData 000h 8001h 0008h 00000001h 00010000h 0000 00h
InIOPS 000h 8002h 0009h 00000001h 00020000h 0001 80h
InData 000h 8002h 0009h 00000001h 00020000h 0000 00h
