om 5184516-100 Rev. 5 5-40
Tube 2
Add Step
NOTE: When building and modifying steps in your Protocols, it is important to remember
your Protocol routine and the order the steps are placed in the Protocol. As a ben-
efit, the Tube Bucky button on the IDD will move in descending order through the
Tube 2 steps. If you have the Pulsed Fluoro option, the digital button on the IDD
not only will return you to fluoro from a Tube 2 step but can toggle you between
continuous and pulsed fluoro.
If you are modifying a Protocol the screen will appear with the Tube selection for
the first step in that Protocol.
ILLUSTRATION 5-40
TUBE SELECTION SCREEN
To modify a specific Tube 2 technique, touch the row you wish to change and
press Edit Tech.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
