7-4 SG120 Specifications
7-4-1 Wall Stand “General”
7-4-2 Wall Stand Bucky
Parameter Specification
Weight 220kg (485.1 lbs)
Height 2235 mm (87.99 in)
Min. Width 652 mm (25.67 in)
Max. Width 915 mm (36.02 in)
Min. Depth 687 mm (27.05 in)
Max. Depth 927 mm (36.5 in)
Front panel height 64.2 cm (25.2 in)
Front panel width 65 cm (25.6 in)
Distance Front Panel to Film
Plane
5.8 cm (2.28 in)
Min. Height (Bucky vertical) 33 cm (13.1 in)
Max. Height (Bucky vertical) 190.5 cm (75 in)
Min. Height (Bucky horizontal) 63.5 cm (25 in)
Max. Height (Bucky horizontal) 213 cm (83.9 in)
Bucky rotation range 0° to 180°
Bucky Angulation range -20° to 90°.
Grid Holding Force >196N
Wall stand panel Filtration Maximum 0.65 Al equivalency at 100 kVp
Bucky Loading Left hand or Right hand
Cassette Load Left Hand (Right hand load field configurable)
Power Supply Single phase voltage: 115, 230V+/-10%+ground
Line Frequency 50/60 Hz
Max. Current (Moment.) 0,4
Max. Current (Continuous) 0,2
Panel to front column distance 550 mm (21.65 in)
Panel to front cover distance 483 mm (19.01 in)
Parameter Specification
Grid 36L/cm; 180 cm focus
Cassette Size Sensing 3 cm×18 cm (5 in.×7 in.) minimum to 35 cm×43 cm
(14 in.×17 in.) maximum
