om 5184516-100 Rev. 5 12-6
2-6Knee Crutches (Optional)
Used for urological or gynecological examinations the crutch supports for the
knees are adjustable (ILLUSTRATION 12-7).
To attach:
1. Spread the hinges on each side,
2. Place on the table top so that the catches on the hinges are roughly in line
with a set of notches and release the hinges.
3. A slight movement back and forth is necessary to obtain positive engage-
ment.
ILLUSTRATION 12-7
KNEE CRUTCHES
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
