CHAPTER 11
JEDI GENERATOR
SECTION 1
INTRODUCTION
TABLE 11-1
ALTITUDE AND ATMOSPHERIC PRESSURE
TABLE 11-2
HEATS OUTPUTS (BY COMPONENT)
SECTION 2
RADIATION PROTECTION
Because X–ray equipment produces radiation, special precautions may need to
be taken or special site modifications may be required. The General Electric Com-
pany does not make recommendations regarding radiation protection. It is the
purchaser’s responsibility to consult a radiation physicist for advice on radiation
protection in X–ray rooms.
SECTION 3
SYSTEMS CABINET SPECIFICATIONS
The JEDI generator is available in two three–phase models (65 kW and 80 kW).
3-1Generator Cabinet Specifications
See ILLUSTRATION 11-1 and TABLE 11-3
PRODUCT OR
COMPONENT
ALTITUDE ATMOSPHERIC PRESSURE
IN–USE STORAGE IN–USE STORAGE
MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX.
Generator –30.5
(–100 ft.)
2440 m
(8005 ft.)
–30.5 m
(–100 ft.)
3048 m
(10000 ft.)
10 psi
(69 kPa)
15.4 psi
(106 kPa)
7 psi
(48 kPa)
15.4 psi
(106 kPa)
PRODUCT OR
COMPONENT
MAXIMUM HEAT OUTPUT (BTU/HR) MAXIMUM HEAT OUTPUT (WATTS)
IN–USE IN–USE
Generator 2036 597
FOR TRAINING PURPOSES ONLY!
