2-6Rear View of Collimator
(1) Locking lever for 90° rotation of collimator around vertical axis
ILLUSTRATION 8-11
AUTOMATIC COLLIMATOR REAR VIEW
2-7Collimator Lamp Changing
2-7-1 Changing Lamps on the Collimator (Model 2266999)
The bulb of the collimator may be changed if necessary.
Locking lever for rotation of
collimator around vertical
axis.
Identification labels.
