GE Precision 500D User Manual

om 5184516-100 Rev. 5 9-11
SECTION 7
SPECIFICATIONS
7-1 Electrical Requirements
Electrical requirements for the SG80/120 vertical bucky stand:
7-2 Product Dimensions
7-3 Crate Dimensions
The SG80/120 is packed in only one crate with the next dimensions:
PRODUCT
FREQUENCY (Hz) VOLTAGE (V) MAX CURRENT (A)
MIN MAX MIN MAX Moment.
Continu-
ous
SG80/120 50 60 115 230 0.4 0.2
RODUCT
DIMENSIONS
WEIGHTDEPTH WIDTH
HEIGHT
MAX MIN MAX MIN
SG80
373 mm 373 mm 652 mm 652 mm 2235 mm 180 Kg
14.69 in 14.69 in 25.67 in 25.67 in 87.99 in 396.9 lbs
SG80 W/
SPACER
637 mm 637 mm 652 mm 652 mm 2235 mm 194 kg
25.08 in 25.08 in 25.67 in 25.67 in 87.99 in 427.8 lbs
SG120
927 mm 687 mm 915 mm 652 mm 2235 mm 220 kg
36.5 in 27.05 in 36.02 in 25.67 in 87.99 in 485.1 lbs
PRODUCT
DIMENSIONS
WEIGHT
DEPTH WIDTH HEIGHT
SG80
940 mm 2410 mm 890 mm 80 kg
37.01 in 94.88 in 35.04 in 176.4 lbs
SG120
940 mm 2410 mm 890 mm 80 kg
37.01 in 94.88 in 35.04 in 176.4 lbs
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
