om 5184516-100 Rev. 5 8-20
SECTION 3
SPECIFICATIONS
NOTE: Because X–ray equipment produces radiation, special precautions may need
to be taken or special site modifications may be required. The General Elec-
tric Company does not make recommendations regarding radiation protec-
tion. It is the purchaser’s responsibility to consult a radiation physicist for
advise on radiation protection in X–ray rooms.
NOTE: There is an Overheat Interlock on the X–ray Tube Housing. If the factory–
adjusted temperature of the tube housing goes higher than the permissible
level, x–ray emission is terminated. If this occurs, call for service.
TABLE 8-3
RELATIVE HUMIDITY AND TEMPERATURE
TABLE 8-4
ALTITUDE AND ATMOSPHERIC PRESSURE
PRODUCT OR
COMPONENT
RELATIVE HUMIDITY TEMPERATURE
IN–USE
STORAGE IN–USE STORAGE
MIN.
MAX. MIN. MAX. MIN. MAX. MIN. MAX.
OTS 10% 80% 5% 95%
+10C
(50F)
40C
(104F)
–40C (–
40F)
+70C
(158F)
X–ray Tube 10% 80% 5% 95% +10C
(50F)
40C
(104F)
–40C (–
40F)
+70C
(158F)
PRODUCT OR
COMPONENT
ALTITUDE ATMOSPHERIC PRESSURE
IN–USE
STORAGE IN–USE STORAGE
MIN.
MAX. MIN. MAX. MIN. MAX. MIN. MAX.
OTS
–400 m
(–1312 ft.)
3000 m
(9842 ft.)
–400 m
(–1312 ft.)
15000 m
(49212 ft.)
10.17 psi
(70.1 kPa)
15.4 psi
(106 kPa)
1.75 psi
(12.1 kPa)
15.4 psi
(106 kPa)
X–ray Tube –400 m
(–1312 ft.)
3000 m
(9842 ft.)
–400 m
(–1312 ft.)
15000 m
(49212 ft.)
10.17 psi
(70.1 kPa)
15.4 psi
(106 kPa)
1.75 psi
(12.1 kPa)
15.4 psi
(106 kPa)
