GE Precision 500D User Manual

om 5184516-100 Rev. 5 8-21
TABLE 8-5
OTS SPECIFICATIONS
Parameter
Specification
Longitudinal Focal Spot Travel 2757 mm (108–1/2 in.)
Lateral Focal Spot Travel 1200 mm (47–1/4 in.)
Vertical Focal Spot Travel 1500 mm (59 in.)
Horizontal Tube Rotation +/– 180 degrees; detents at each 90 degree position
Vertical Tube Rotation + 110/–20 degrees
Focal Spot to Ceiling Distance (Horizontal) Min 733mm (28–7/8 in.) Max 2232mm (87–7/8 in.)
Focal Spot to Ceiling Distance (Vertical) Min 713mm (28–1/16 in.) Max 2211mm (87–1/16 in.)
Distance between Center Lines of Ceiling
Mounting Bolt Holes in Stationary rails
1.43m(56”), or 1.27m(50”), or 1.22m(48”)
Minimum Overall Room Dimension, Front
to Back, without Modifying Basic Structure
3.2m (124–1/4”)
OTS Suspension Weight 431kg (50lbs)
OTS Console
kV Control and Display 40–150
mAs Control and Display 0.5–630
SID Display 0–200
Tube Angle Display –180 to +180
Power Supply
OTS Console +5VDC, 2.5A
+12VDC, A
– 12VDC, A
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).

GE Precision 500D Specifications
