TABLE 7-5 (CONTINUED)
AUXILIARY DIGITAL OPERATOR CONSOLE
Item
Operator
Control
Activated
Display
De-Acti-
vated
Display
Description Notes
7 Press to move the last image hold (LIH) on
monitor 1 to monitor 2 as a reference
image. This image will remain on monitor 2
until another image is transferred. (Images
are not saved to hard disk).
Press to remove the last image hold (LIH)
from monitor 1 to monitor 2.
Available with 2 Monitor
option.
8 Press to activate Fluoro Loop Acquire.
Selection will highlight.
When Fluoro is started, fluoro images are
stored to image RAM. Depending on the
system configuration, a maximum of 128
images (4 secs at 30 frames per second) or
a maximum of 256 images (8 secs at 30
frames per second) are stored. By press-
ing the fluoro pedal again this loop willl be
overwritten if not saved to hard disk.
When fluoro is stopped, the acquired loop
will be automatically begin playback in
order to review the loop. CAUTION: The
loop has not been stored to hard disk at this
point. The user must press the Fluoro Loop
Store button (described below) in order to
permanently save the fluoro loop to the
hard disk.
Optional Feature
9 Selection will appear after a fluoro loop has
been acquired. Pres to transfer to hard
drive from RAM memory
Note: Fluoro cannot be performed during
transfer; information will be lost.
10 Selection will appear after Fluoro. This will
save and number the current last image
hold (LIH) to the hard drive.
11 Changes frames per second for host Flu-
oro.
Note: If pulsed Fluoro is selected, the
default f/s is displayed.
When button is pressed,
host Fluoro will cycle
through the selections:
15, 7.5, 3.75.
12 Selecting this button will switch the system
from fluoro to the first OTS films. By press-
ing it again, it will cycle through the proto-
col.
