GE Precision 500D User Manual

om 5184516-100 Rev. 5 8-8
TABLE 8-2
OTS OPERATOR CONTROLS AND INDICATORS
Item Title Type Description
1 kV Display Indicator Display exposure kV.
2 mAs Display Indicator Display exposure mAs.
3 kV Increment and Decrement
Keys
Control Increase or Decrease exposure kV.
4 mAs Increment and Decrement
Keys
Control Increase or Decrease exposure mAs.
5 Unit Display Indicator Display SID scale.
6 SID Display Indicator Display SID scale.
7 Angulation Display Indicator Display tube rotation angle.
8 Tube Angulation Lock Release Control Releases magnetic lock to allow tube angulation.
9 Vertical Lock Release Control Releases magnetic lock to allow vertical tube motion.
10 All Lock Release Control Releases all OCS magnetic locks to allow vertical, transverse,
longitudinal, and tube angulation motions. Note: If in lateral or
vertical detent the lateral or vertical lock will not be released.
The DETENT button MUST be released. ÁÁÁ
11 All Lock Release Control Releases all OCS magnetic locks to allow vertical, transverse,
longitudinal, and tube angulation motions. Normally open
momentary type button, without indicator. Note: If in lateral or
vertical detent the lateral or vertical lock will not be released.
The DETENT button MUST be released. ÁÁÁ
12 MANU. COLI Indicator Indicates that the collimator is working in manual mode
13 Exposure Hold Exposure Indicates for some reason an exposure is not permitted. ÁÁÁ
14 READY Exposure This button is lit when the system is ready for exposure.
15 DETENT Control Lock or Release the Detent magnetic lock. Normally open self–
lock type button.
16 Lateral Lock Release Control Release magnetic lock to allow lateral motion. Normally closed
self–lock type button, with green indicator.
17 Longitudinal Lock Release Control Release magnetic lock to allow longitudinal motion. Normally
closed self–lock type button, with green indicator. ÁÁÁ
18 Table Top Receptor Selects the Table Top as the image receptor
19 TABLE Receptor Selects the table bucky/cassette tray as the image receptor
ÁÁÁ
20 WALL Receptor Selects the Wall Stand Film Cabinet as the image receptor.
21 Function Not available at this time
22 Collimator Select Control Select the operating mode of the auto collimator (Behind the
console)
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
