om 5184516-100 Rev. 5 10-4
Vertical Bucky travel:
• Top edge of Bucky in vertical position: from 24.57” (624 mm) to 72.60” (1844
mm).
• Top edge of Bucky in horizontal position: from 20.77” (527.5 mm) to 68.07”
(1729 mm).
Tolerance: + 0.0” (0 mm), –0.6” (15 mm)
The mechanical backup lock engages within 1/2” (12.7 mm) of vertical travel in
the event the holding power (44 Ibs/19.8 kg) of the electromagnetic locks is
exceeded, or in the event of lock failure or an unbalanced condition between the
Bucky carriage assembly and the counterweights in the vertical column.
The mechanical backup lock is capable of supporting 176 Lbs (79.2 kg).
3-3Patient Support Legs
When the Bucky is in the horizontal position, two foldable legs can be used to
allow a patient to sit on the Bucky. To unfold the legs, pull the lock release knob
located on the right-side leg.
WHEN USING PATIENT SUPPORT LEGS, ENSURE THEY ARE FIXED
IN A POSITION THAT CANNOT INJURE THE PATIENT OR DAMAGE
THE EQUIPMENT.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
