om 5184516-100 Rev. 5 A-6
ILLUSTRATION A-2
OUTLINE DRAWING
OUTLINE DRAWING MX–100–09 AND 100-18
OUTLINE DRAWING MX–100–FL
NOTE: ALL DIMENSIONS SHOWN ARE IN
INCHES (MM) NOMINAL VALUES
NOTE: ALL DIMENSIONS SHOWN ARE IN
INCHES (MM) NOMINAL VALUES
FOR TRAINING PURPOSES ONLY!
