om 5184516-100 Rev. 5
REV HISTORY
REV DATE REASON FOR CHANGE
1 September 21, 2006 Initial Release
2 May 16, 2007 Changed “power on” and “reset” instructions to indicate the
buttons being located on the RCIM instead of the IUI.
Updated model numbers in Table 7-1 an throughout docu-
ment.
Removed references to “hardcopy output” to match current
system configuration.
Changed labels on illustration of key switch on OTS con-
sole.
Removed Table 11-1, information no longer applies.
3 August 17, 2007 Removed RCIM from Illustration 7-2 and Table 7-1;
replaced with Operator Console. Added and updated part
numbers in Table 7-1 rows 1, 4, and 6. Removed “X-Ray
control” from row 8, JEDI Generator.
4 October 3, 2007 Updated Table 7-1, Items 6 and 8 to identify X-ray control
unit depending upon date of manufacture. Added model
numbers to Table 7-1 row 1(Overhead tube Collimator) and
row 4 (Precision 500D R&F Table Collimator).
Added note about radiopacity after table 7-12.
Added ifnormation on collimator lamp replacement for
model 5234954 in Chapter 8.
Added mR/mAs calibration and maintanence frequency to
table in Appendix B section 3-1.
5 November 26, 2007 Updated list of international keyboard options to show cur-
rent supported languages of English and German.
Added text of hardware label to Illustration 8-7.
LIST OF EFFECTIVE PAGES
PAGE NUMBER REVISION NUMBER
3-2 5
4-3 5
8-9 5
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
