RSDetection
User’s Manual
March 2016 S131-200-UM Rev A
Page 44
5.3.3.6 Serial Port Configuration Parameters
The number of serial ports available for configuration (if any) is determined by the number
of USB to serial port adapters connected. A serial port requiring configuration is enabled
within the RSDetector unit for each device connected.
Table 13 Serial Ports Configuration Parameters
Determines the BAUD rate of the
serial port.
A drop down list
determines the
choices.
The number of bits used in the
transmission of a character.
Parity of the transmitted byte.
A drop down list
determines the
choices or Even,
Odd or None.
5.3.3.7 RSDetection Configuration Parameters
This selection covers a number of properties that govern the overall system operation.
Table 14 RSDetection Configuration
If true, the high voltage bias
(nominally 400V) will be applied at
startup.
A global enable that when false will
disable all logging and if true logging
will be determined by the
measurement or event configuration.
A global enable that when false will
disable all notifications and if true
logging will be determined by the
measurement or event configuration.
The older units allowed for 3 types of
date output. This corresponds to the
legacy DTF command.
MM_DD_YY
DD_MM_YY
YY_MM_DD
The legacy commands used a single
character address for selecting which
unit was being addressed. This
corresponds to the UID legacy
command.
Single character
from ‘0’ to ‘Z’
excluding ‘@’
