GE Solar 8000M/i User Manual

3-6 Solar 8000M/i patient monitor 2026265-075C
Installation: Back panel connections
DFP VID 1 and 2
Two DFP (Digital Flat Panel) connectors provide an interface to digital
displays. The connector is a 20-pin, MDR type.
RS-232 1
The RS-232 1 serial connector provides an interface to the iPanel
computer. If not using an iPanel, it interfaces to a PC for software
upgrades or polled-parameter service. The connector is a 9-pin, D type.
RS-232 2
The RS-232 2 serial connector provides a touchscreen interface. The
connector is a 9-pin, D type.
NOTE
Use cable 2006733-00X for touchscreen connection. The cable
supplied with the display will not work.
014C
