IC200MDL631
Input Module, 125VDC Pos/Neg Logic Isolated 8 Points
Module Specifications
Module Characteristics
Points 8 isolated inputs
Module ID FFFF8004
Isolation:
User input to logic (optical)
and to frame ground
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
LED indicators One LED per point shows individual point ON/OFF status
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 40 mA maximum
External power supply None
Thermal derating No derating
Configuration parameters Input response times
Input Characteristics
Input voltage 0 to +150VDC, +125 VDC nominal
User input current 1.7mA typ. @ 125VDC, 2.2mA typ. @ 150VDC
Input impedance 74K Ohm typ. @ 125VDC
On state voltage 90VDC to 150VDC
Off state voltage 0VDC to 30VDC
On state current
Off state current
1.0mA minimum
0 to 0.1mA maximum
On response time
Off response time
0.5ms maximum
Configurable filter time 0ms, 1.0ms (default), or 7.0ms
