IC200MDL640
Input Module, 24VDC Pos/Neg Logic 16 Points
Module Specifications
Module Characteristics
Points 16 inputs (2 groups of 8)
Module ID FFFF8008
Isolation:
User input to logic (optical)
and to frame ground
Group to Group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point ON/OFF status
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 25mA maximum
External power supply None
Thermal derating No derating
Configuration parameters Input response times
Input Characteristics
Input voltage 0 to +30VDC, +24VDC nominal
On state voltage +15 to +30VDC
Off state voltage 0 to +5.0VDC
On state current
Off state current
2.0 to 5.5mA
0 to 0.5mA
On response time
Off response time
0.5ms maximum
Configurable filter time 0ms, 1.0ms (default), or 7.0ms
Input impedance 10kOhms maximum
