GFK-1504K Chapter 8 Discrete Output Modules 8-3
8
IC200MDL329
Output Module, 120VAC 0.5 Amp, Isolated 8 Points
Module Specifications
Module Characteristics
Points 8 isolated outputs
Module ID FFFF8840
Isolation:
User input to logic (optical)
and to frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
Not applicable
250VAC continuous; 1500VAC for 1 minute
LED indicators One LED per point shows individual point on/off state
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 70mA maximum
External power supply 85 to 132VAC (47 to 63Hz), 120VAC nominal
Thermal derating See Diagram
Output Characteristics
Output voltage 85 to 132 VAC (47 to 63Hz), 120VAC nominal
Output voltage drop 2.0V maximum
Load current
10mA minimum per point
0.5A maximum per point
5.0A for one cycle (20ms) maximum inrush
Output leakage current Less than 2mA at 132VAC
On response time
Off response time
Less than ½ cycle, maximum
Less than ½ cycle, maximum
Protection Snubber and MOVs (each output)
Diagnostics None
