IC200MDL330
Output Module, 120VAC 0.5 Amp, Isolated 16 Points
Field Wiring
Terminal Connection Terminal Connection
A1 Output 1 B1 Output 9
A2 Output 1 Ret B2 Output 9 Ret
A3 Output 2 B3 Output 10
A4 Output 2 Ret B4 Output 10 Ret
A5 Output 3 B5 Output 11
A6 Output 3 Ret B6 Output 11 Ret
A7 Output 4 B7 Output 12
A8 Output 4 Ret B8 Output 12 Ret
A9 Output 5 B9 Output 13
A10 Output 5 Ret B10 Output 13 Ret
A11 Output 6 B11 Output 14
A12 Output 6 Ret B12 Output 14 Ret
A13 Output 7 B13 Output 15
A14 Output 7 Ret B14 Output 15 Ret
A15 Output 8 B15 Output 16
A16 Output 8 Ret B16 Output 16 Ret
A17 No connection B17 No connection
A18 No connection B18 No connection
When wiring outputs to inductive loads, use of external suppression circuits is
recommended. See chapter 2, "Installing Wiring for I/O Devices-Wiring to Inductive
Loads" for more information.
Wiring Connections
for Carriers with Two
Rows of Terminals
IC200CHS002, 005
IC200CHS012, 015
Q1 Q2 Q3 Q4 Q5 Q6 Q7 Q8
Q9 Q10 Q11 Q12
Q13
Q14
Q15
Q16
1 2 3 4 5 6 7 8 9 11 12 13 14 15 16 17 18
123456789 111213141516171810
10
B
A
Wiring Connections
for Carriers with Three
Rows of Terminals
IC200CHS001, 022, 025
IC200CHS011
A
123456
13
14 15 16 17 18
789 111210
Q1 Q2
Q4
Q8
Q3
Q5
Q6
Q7
~~
~
~
~
~
~
~
B
123456
13
14 15 16 17 18
789 111210
Q9 Q10
Q12
Q16
Q11
Q13
Q14
Q15
~~
~
~
~
~
~
~
